XRC 50-30LC T (100kV) X-ray Scanner – Small Parcel & Baggage

XRC 50-30LC T (100kV)

SMALL PARCEL AND BAGGAGE

With the help of 100kV generator power, this model x-ray baggage scanner facilitates the operators use thanks to the various image processing functions, hazard alarm, advanced computer technology and the best in class software. XRC 50-30 enables easy identification of potentially threatening objects such as cutting tools, explosives narcotics and minimizes the error rate. Thanks to its multi-diode structure and quality in imaging of scanned objects, image is colored based on density and shows organic, inorganic and mixed materials in different tones.

XRC 50-30LC T is a preferred model for locations with limited operating space. It is designed with the latest technology to scan small handbags, packages, parcels and cabin baggage in detail. It is an efficient and a powerful x-ray scanning device that allows inspection in courts, police departments, offices, shopping malls, prisons and hotels .

Downloads

XRC 50-30LC T (100kV) (english)

0.54MB

XRC 50-30LC T (100kV) (german)

0.59MB

XRC 50-30LC T

APPLICATION AREAS

POLICE AND JUSTICE

AIRPORTS AND BORDER CROSSINGS

GOVERNMENT BUILDING

DISTRIBUTION CENTERS LOGISTICS HUBS

CUSTOMS BORDER CONTROL

CRITICAL INFRASTRUCTURE

FEATURES & SPECIFICATIONS

XRC 50-30LC

PROGRAMMABLE FUNCTION KEYS PARCEL COUNTER
DATE AND TIME DISPLAY
VIRTUAL THREAT IMAGE PROJECTION (TIP)
ORGANIC/INORGANIC THREAT ALARM OPERATOR
TRAINING PROGRAM (OTP)
UPS (FOR COMPUTER SUPPLY)
MULTI LANGUAGES
SELF DIAGNOSIS
GENERATOR TIMER AUTOMATIC STOP CONVEYOR

XRC 50-30LC

BARCODE READER SYSTEM
EXTERNAL CAMERA ARCHIVING
REMOTE VIEWING STATION
RECHECK STATION
NETWORK SUPERVISORY SYSTEM (NSS)
REMOTE ACCESS CONNECTION
SMART CARD LOGIN

XRC 50-30LC

TUNNEL SIZE: 532 mm x 332 mm
DIMENSIONS: 2,300 mm x 1,300 mm x 770mm
APPROX. WEIGHT UNPACKED: ~450 kg
CONVEYOR HEIGHT: 615 mm
CONVEYOR LOAD CAPACITY: 165 kg Evenly Distributed
SYSTEM POWER: 110/220V AC ± 10% 50/60 Hz
CONVEYOR SPEED: 0.20 m/sec. Forward or Reverse
STEEL PENETRATION: 9 mm guaranteed; 10 mm typical
WIRE RESOLUTION: 38 AWG guaranteed; 40 AWG typical
ANODE VOLTAGE: 100 kV, operating at 90 kV
TUBE CURRENT: 0.5 mA
BEAM DIRECTION: Vertically upward
ARTICLE SEPARATION: Low Z, Medium Z, High Z to 0.5 Z Accuracy
COOLING: Oil and forced air cooling

XRC 50-30LC

PROCESSOR: Intel® Core™ i5 (or superior)
MONITOR: 21.5” Flat (or superior)
MEMORY: 4 GB RAM (or superior)
VIDEO CARD: 2 GB (or superior)
HARD DRIVE: 1 TB (or superior)
USB PORT: 6 port (or superior)
OPERATING SYSTEM: Linux
